DMG DECKEL MAHO DMU 50

DMG DECKEL MAHO DMU 50

This 5-axis DMG DECKEL MAHO DMU 50 vertical machining centre was manufactured in 2005. It features a Heidenhain iTNC 530 control, a main spindle speed range of 20 - 10,000 RPM, and a rotary table with a clamping surface of 630 x 500 mm. The machine has undergone significant overhauls, including a complete X-Axis bearing replacement and new coolant pump installation. If you are looking to get high-quality milling capabilities, consider the DMG DECKEL MAHO DMU 50 machine we have for sale. Contact us for more information.

Additional equipment


• Tool Positions: 16 / Max. Tool Weight: 6 kg / Max. Tool Length: 300 mm

• Max. Tool Diameter: Without adjacent tools: 130 mm / With adjacent tools: 80 mm

• Total Power Requirement: 17 kVA

• No chip conveyor included / No automatic measuring probe included / No tools included

Machine Benefits

Qualitative Machine Benefits


• Low spindle hours and power-on hours.

• Never used in series production; operated with care and proper procedures.

• Warm-up programs and maintenance routines followed for optimal performance.

Technical Machine Benefits


• Torque: 57 / 82 nm / rapid traverse (x/y/z): 12 m/min /feed rate: 10000 mm/min

• Table clamping surface: 630 x 500 mm

• Swivel range: -5 / +110°

• Max. Table load: 200 kg

• T-slots: 14 h7 / t-slot spacing: 63 mm

• C-axis rotation: +/- 360°

• Complete x-axis bearing overhaul including ball screw and bearing assembly. / various hydraulic components overhauled. / tool changer readjusted and sensor system replaced.

• New door switch installed. / new discs installed (with some chip debris affecting them). / new coolant pump installed. / new screen installed. / new handwheel hr410 installed.

• Machine is 5-axis machine with 3+2 configuration

Technical Specification
Taper Size SK 40
