Obradni centar - univerzalni

DMG DECKEL MAHO DMU 80 P duoBlock

x-travel 800 mm
y-travel 1.050 mm
z-travel 800 mm
control 840D solutionline Siemens
Speed Mainspindle max. 10.000 min/-1
power capacity - main spindel 44 kW
max. Torque 288 Nm
tool taper HSK-A 100 DIN 69893
Swivel range -10° / +180 °
table surface area dia. 900 x 700 mm
max. table load 1.500 kg
distance spindlenose - table horizontal 50 - 850 mm
distance spindlenose - table vertical 150 - 950 mm
table speed 35 min/-1
rotatable C: 360 °
number of toolpositions 120 pos.
tool taper HSK-A 100
max. tool diameter 110 mm
max. tool-dia with free toolbox 230 mm
max. tool length 550 mm
max. tool weight 30 kg
tool changing time 5,4 sec
rapid traverse ( X / Y / Z ) 60 m/min
Rapid B-Axis 23 min/-1
Accelaration 7 / 6,5 / 6,5 m/s²
Ledpfx Abszc Rqwoyeac
Feed force ( X / Y / Z ) 13 / 13 / 9 kN
weight of the machine ca. 13,0 t
dimensions of the machine ca. 6,0 x 5,5 x 3,7 m
total power requirement 80 kVA
5 Axis Machining Center - Universal
DMG DECKEL MAHO - DMU 80 P duoBLOCK

- Spindle replacement: May 2025

- controled Swivel-Milling-Head / Gear-Spindle (B-Axis)
- NC-Rotary Table (C-Axis)

- Tool identification
- 3D machining, 3D tool compensation
- TRANSMIT cylindrical surface transformation (milling of cylindrical paths)
- CompCad compressor function for high-speed machining

- WITHOUT tools
