Mazak VERTICAL CENTER NEXUS 510C-II

Mazak Vertical Center Nexus 510C-II

This 3-axis Mazak Vertical Center Nexus 510C-II was manufactured in 2008. It features an impressive X-axis travel of 1050 mm, Y-axis travel of 510 mm, and Z-axis travel of 510 mm. The machine includes a robust table size of 1300 x 550 mm and a maximum table load of 1200 kg. If you are looking to get high-quality machining capabilities, consider the Mazak Vertical Center Nexus 510C-II machine we have for sale. Contact us for further details.

- Control System: Mazatrol Matrix Nexus (with Mazak Voice Adviser)- Axis Travel X/Y/Z: 1050 / 510 / 510 mm- Table Dimensions: 1300 x 550 mm- Maximum Table Load: 1200 kg- Spindle Speed: Up to 12000 rpm- Spindle Details: Completely renewed in September 2025 by Mazak factory service (original replacement spindle cartridge, high-precision version, clamping force 10.1 kN, runout 0.002-0.005 mm)- Tool Taper: SK 40 / BT 40- Tool Magazine Capacity: 30 stations- Tool Changer Type: Double gripper changer- Rapid Traverse Rate: Up to 42 m/min- Total Power-On Time: 46722 hours (as of 07.07.2026)- Automatic Operation Time: 17776 hours- Cutting Time: 15817 hours- Pure Cutting Time: 13169 hours- Weight: Approx. 6920 kg- Power Supply: 3AC 380 V, 50/60 Hz, approx. 33.8 kVA- Control Circuit: AC100V, DC24V- Main Motor: Max. 47 A, 400 V- Included Accessories / Components:* Chip conveyor (chain conveyor) with discharge to chip container* Donaldson Torit DCE oil mist separator* Portable electronic handwheel* Coolant system with spray gun / compressed air gun* Machine vise (NC vise)* Approx. 100 SK 40 tool holders* Tilting chip container (green cart)* Worklight / interior lighting* Full enclosure- Renewed parts during 09/2025 service: Spindle cartridge, rotary joint, non-return valves, filters for air/lubricating oil, oil mist separator element

Technical Specification
Taper Size SK 40
