Mašina za brušenje četkom MB Roba Tech 1300

MB Maschinenbau Roba Tech 1300

Equipment:

- Brush grinding machine with rotating grinding brush belt
- Motorized height adjustment of the grinding unit,
adjustment range from approx. 0 - 80 mm,
freely programmable via machine control.
- Operating side in the direction of travel, right
- Rotating brush set consisting of
174 segment brushes, length 1,300 mm.
Segments are easy to change and are
inserted into the brush belt from the side.
- With vacuum conveyor belt
- With cleaning roller for the feed belt
Technical data:
- Working width: 1300 mm
Fodpfxexrb Rfs Ab Esgk
- Max. part thickness approx. 80 mm
(depending on the abrasive coating)
- Working height: 850 - 900 mm
- Year of manufacture 2014
- Feed continuously adjustable, 3 m/min-10 m/min
- Machine length: 3860 mm
- Machine width: 2400 mm
- Machine height: 2000 mm
- Paint finish in RAL 7035, light gray with
- Contrast color green
- Voltage: 400V/50HZ
- Electrical connection 16kW/36A
- Machine weight: approx. 2600 kg
