Okvirna pila za tanko rezanje

NEVA POWER Plus

The POWER Plus Thin Cutting Frame Saw was developed to be affordably priced for companies with medium to small production needs. The machine has a sturdy, solid cast iron base and is equipped with a 15 kW (20 HP) main motor. The Frame Saw cuts solid wood blocks into gluable slats with minimum saw kerf waste. The machine can run products up to 150 mm in width and 250 mm in height. The POWER Plus Thin Cutting Frame Saw provides the smaller manufacturer a high performance and quality machine for the production of their veneer slats/lamellas; all for an affordable price.

Applications of use: Parquet and engineered flooring, doors, windows, stairs, furniture, musical instruments, pencils, sport equipment (ski, snowboards, hokey sticks), wooden-covers for fruit and vegetables, etc.

Features:
High precision lamellas with gluable surface in tolerance ± 0.1 mm, depending on lamellas width
The "Plus" System is designed for quick set-up and easy adjustment of the top pressure rollers via electrical motor
Air Blast system located directly behind the saw blades keeps the saw blades clean and prevents heat build-up
Automatic Opening of the machine for safe and easy removal and installation of the saw frame
Sturdy and durable Cast Iron Saw Frame Carriage no play mounted on linear guides
Feed roller movement is synchronized with the up/down movement of the saw frame
Modular Infeed can accommodate a center guide, side guide or channel system
Fgsdjy Rk Umopfx Aiyob
Chip Breaker prevents splintering on the bottom side of the wood
Solid cast iron machine construction minimizes vibration
Top and Bottom Driven Feed Rollers
Automatic Central Lubrication Unit
Solid Steel Crank Arms

On demand Features:

Top and Bottom Planing Module on machine outfeed
Air Jet system for cooling with extra ventilator
Top Planing Module on machine infeed
Automatic Hopper Feeder
Wet Way Cutting Option
Blades Tension Master
