Fliegl SDS 380 Containerchassis Vario V3

Custom-made transport solution
Configure your Fliegl vehicle according to your requirements. The vehicle shown is an example. Production and equipment are carried out individually according to customer requirements.

Chassis, saddle, container
Fine-grained steel welded construction, saddle plate with 2 interchangeable kingpins and 2 kingpin positions
Container receptacles:
Rear extension retracted:
1 x 20 ft or 1 x 30 ft, flush at the rear
Middle telescope, 1st stage, rear extension extended, 1st stage:
2 x 20 ft or 1 x 40 ft with and without gooseneck tunnel
Middle telescope, 2nd stage, rear extension extended, 2nd stage
1 x 45 ft with gooseneck tunnel and rear overload
Middle telescope, 2nd stage, front extension extended, 1st stage
Rear extension extended, 2nd stage
1 x 45 ft with long gooseneck tunnel and angled corners
Middle telescope as an interlocking central tube frame with pin locking
without height adjustment at the rear and without folding center supports, transport of containers without a tunnel is not possible.
2 container guides, incl. connecting plate for electrical, air, and brake connections
Plug adapter for front locking, to lock containers without a tunnel from below, with holder when not in use
Front extension mounted on rollers, manually extendable (for 45 ft containers with long tunnels)
Rear extension mounted on rollers, with hand crank
24 tons, 2-speed support winch, single-sided operation
Retractable underrun protection for 45 ft containers
Rear impact protection
Axles + suspension
SAF disc brake axles with 430 mm disc diameter
Axle/chassis laser-measured, reducing tire wear and fuel consumption
Axle spacing offset mm (combined transport) up to 44 tons total vehicle weight
Dcodpfoi Ri E Ajx Abmoh
Air suspension
1st axle automatic lift axle, including forced lowering and start-up assistance, actuation 3x brake
Brake system
2-line pneumatic brake system, color-coded lines for easy servicing
Spring-loaded parking brake
Tele Control
Axle load adjustment for easy telescoping
2 keyed coupling heads at the front, without connection cable
EBS, electronic brake system with EBS socket at the front, without connection cable
Note: The trailer may only be pulled by tractor units which ensure the effectiveness of the ABS!
with raise and lower valve
Vehicle - driving stability system
Axle load detection via EBS-CAN bus signal, for display on the display in the driver's cab, truck must be prepared accordingly, no truck installation (no calibrated scale)
Wheels and tires
385/55 R22.5, manufacturer's choice
Steel rims, factory silver
Electrical system
24 Volt, 4 x 3-chamber lights + 1 round reversing light and + 1 round rear fog light, yellow LED lighting on the sides
2 white position lights at the front
2 white/red marker lights at the rear
2 x 7-pin keyed sockets at the front, without connection cable
Operating instructions
When transporting 45 ft containers with a short tunnel, with or without a front extension, the permissible system length from kingpin to the rear of the vehicle and the total vehicle length of 16500 mm will be exceeded! The underrun protection must be manually extended! An exemption permit according to § 70 StVZo is required!
Approval / signs
Germany
Test approval according to EC 2007/46
24/7 service hotline
prepared for license plate holder, single-row
Warning sign according to ECE - 70
Contour marking
